Description
Thermal and acoustic insulation of ventilated and non-ventilated pitched roofs with standard rafter spacing, also suitable for insulation of residential containers. To create an effective insulation system in pitched roofs, the use of high quality waterproofing membranes is essential. The products are supplied packed on wooden, non-returnable pallets – 18 rolls of one size per pallet.
| Order number | Thickness [mm] | Dimensions [mm] | Pieces/package | m2 / package | m3 / package | m2 / pallet | m3 / pallet | RD [m2 K/W] | |
| 69010502 | 50 | 1200 x 13000 | 1 | 15,60 | 0,78 | 280,80 | 14,04 | 1,40 | |
| 69010602 | 60 | 1200 x 10800 | 1 | 12,96 | 0,78 | 233,28 | 14,00 | 1,70 | |
| 69010802 | 80 | 1200 x 8100 | 1 | 9,72 | 0,78 | 174,96 | 14,00 | 2,25 | |
| 69011002 | 100 | 1200 x 6500 | 1 | 7,80 | 0,78 | 140,40 | 14,04 | 2,85 | |
| 69011202 | 120 | 1200 x 5400 | 1 | 6,48 | 0,78 | 116,64 | 14,00 | 3,40 | |
| 69011402 | 140 | 1200 x 4600 | 1 | 5,52 | 0,77 | 99,36 | 13,91 | 4,00 | |
| 69011502 | 150 | 1200 x 4300 | 1 | 5,16 | 0,77 | 92,88 | 13,93 | 4,25 | |
| 69011602 | 160 | 1200 x 4000 | 1 | 4,80 | 0,77 | 86,40 | 13,82 | 4,55 | |
| 69011802 | 180 | 1200 x 3600 | 1 | 4,32 | 0,78 | 77,76 | 14,00 | 5,10 | |
| 69012002 | 200 | 1200 x 3200 | 1 | 3,84 | 0,77 | 69,12 | 13,82 | 5,70 |
